BTU 18000
Rated Capacity – Cooling 4543 W
Rated Running Current – Cooling
9.25 A

Rated Capacity – Heating 19500 Btu/h
Rated Running Current – Heating 7.08 A
Rated Power Input – Cooling 1935 W
Rated Power Input – Heating 1612 W
Energy Efficiency Ratio (EER) 3.40
Power supply source 220-240V~/50Hz/1P
Refrigerant R32/0.88kg
Gen Mode Yes
Air Flow Volume 850 m3/h
Outdoor Noise level 55.00 dB(A)
Indoor unit weight （Net ) 9.50 Kg
Outdoor unit weight (Net ) 33 Kg
Net Dimension – Indoor (WidthxDepthxHeight) 920×306×195 mm
Net Dimension – Outdoor (WidthxDepthxHeight) 853×349×602 mm
Split AC installation Cost:
Description (Wall Mounted Split AC 1-2 Ton) Tariff (PKR)
PEL Technician Installation 4500
Dismantling Charges in case of previous AC 2000
Extra Copper Pipe (RFT) 750
PVC Drain Pipe (RFT) 100
Simple Grooving without Pipe Concealing (RFT) 150
Iron Frame Charges (Powder Coated) 2000
Filling of Holes with white Plaster of Paris (RFT) 200
PVC Duct for Refrigeration pipe (RFT) 400
Additional Gas Charging (if required)
**In case of more than 10ft outdoor height (R-22) 350 Per RFT
(R410a) 500 Per RFT
